버블젯 산소 가습 유량계
Bubble Jet Humidifier w/Flowmeter


직접 흡입에 의한 산소 처치환자와 SUCTION 요법을 병행하는 환자에게 산소 흡입시 분무요법을 통해 환자체내의 습도를 조정하여 SUCTION을 용이하게 하고 체내 습도를 조절하여 주는 장비 입니다.

Bubble Jet Humidifier w/Flowmeter



In oxygen treatment patient by a direct suction and at the same time when the patient inhales oxygen, it's device to regulate humidity in the body through atomizing therapy.

PRIMARY SPECIFICATIONS
Model : MM-BJ015A0

Construction
* Flow range : Dual taper 0 ~ 15 LPM
* Increments : 0.5 LPM from 0.25 to 6 LPM
  1 LPM from 6 to 15 LPM
* Accuracy : 0.25 LPM from 0.5 to 6 LPM
  0.5 LPM from 6 to 15 LPM
* Flush flow : 70 LPM
* Filtering : 0.1 Micron
* Humidifier bottle : 500cc
* Relief : 2 PSIG
* Large bore hose tube : 21 ~ 23mm
* Small tube : 3/16" ~ 5/16"
* Converting switch : Bubble to jet

Bubble Jet Humidifier w/Flowmeter
